2022.09.15

[Paper] “THz Filters Made by Laser Ablation of Stainless Steel and Kapton Film” published by WRH professors Junko Morikawa and Saulius Juodkazis

WRH professors Junko Morikawa and Saulius Juodkazis (School of Materials and Chemical Technology) published a paper in Micromachines.

“THz Filters Made by Laser Ablation of Stainless Steel and Kapton Film”

https://doi.org/10.3390/mi13081170

Abstract:
THz band-pass filters were fabricated by femtosecond-laser ablation of 25-μm-thick micro-foils of stainless steel and Kapton film, which were subsequently metal coated with a ∼70 nm film, closely matching the skin depth at the used THz spectral window. Their spectral performance was tested in transmission and reflection modes at the Australian Synchrotron’s THz beamline. A 25-μm-thick Kapton film performed as a Fabry–Pérot etalon with a free spectral range (FSR) of 119 cm1, high finesse Fc17, and was tuneable over ∼10μm (at ∼5 THz band) with β=30 tilt. The structure of the THz beam focal region as extracted by the first mirror (slit) showed a complex dependence of polarisation, wavelength and position across the beam. This is important for polarisation-sensitive measurements (in both transmission and reflection) and requires normalisation at each orientation of linear polarisation.
